Linear Guide R1694

Linear Guide by Rexroth

Linear Guide R1694

INR 7600 INR 8000
Phone Number

+918810316010

Email Address kapoorbearing@gmail.com

Mon-Thu: 10 AM - 2 PM • Fri: 3 PM - 7AM

Other Website Visit our other website
Address 52, GB Road, Shardhanand Marg

New Delhi, India, 110006

Description

Rexroth R1694 linear guide blocks are ultra-compact, low-profile runner blocks designed for high-speed, precision applications where space and weight are critical. The R1694 series belongs to Rexroth’s SNN format—Slimline, Normal length, Low profile—and is ideal for compact automation systems, medical devices, and lightweight machinery. These blocks feature BSHP (Ball Screw High Performance) technology for smoother motion, reduced friction, and extended service life. Key Features of R1694 Blocks Design: Slimline body, low profile, normal length (SNN) Material: Chrome steel with corrosion-resistant options Speed & Acceleration: Up to 3 m/s and 250 m/s² (or 50 m/s² under high preload) Mounting: Top-mount with threaded holes; no flange Lubrication: Not pre-lubricated—requires initial lubrication before use Compatibility: Designed for SNS/SNO ball guide rails 📦 Sample Part Numbers Part Number Rail Size Preload Class Accuracy Class Seal Type Notes R169489410 20 mm C1 H / N SS / LS Chrome steel, compact design R169429410 25 mm C0 N SS Clearance fit, low friction R169449410 25 mm C1 P LS High preload, precision grade Preload Classes: C0 = No preload (clearance fit) C1 = Moderate preload for higher rigidity Seal Options: SS = Standard seal LS = Low-friction seal for reduced drag These blocks are ideal for multi-axis systems, robotic arms, and compact inspection setups where low height and high precision are essential. CAD models and configurators are available through Rexroth’s official tools for integration into design workflows. 169481310 169481410 169421410 169421310
